Descrizione
- D/A convertersTwin Analog Devices AD1955 24-bit DACs
- Digital filter2nd Generation ATF2 up-sampling to 24-bit/384kHz. Linear Phase, Minimum phase or Steep modes.
- Analogue filter2-pole differential Bessel with DC servo (for both XLR and RCA outputs)
- Digital audio inputs1 x AES/EBU, 2 x S/PDIF coaxial and 2 x TOSLINK optical
- USB Audio inputUSB Type B conforms to USB Audio profile 1.0 or 2.0 (user selectable)
- Analogue audio outputsBalanced XLR and unbalanced RCA analogue audio outputs
- CompatibilityUPnP: Linear PCM 16-24 bit, 11.025-192kHz
Local USB media:Linear PCM 16-24 bit, 11.025-192kHz USB Audio1.0: Linear PCM 16-24 bit, 44.1-96kHz USB Audio 2.0: Linear PCM 16-24 bit, 44.1-192kHz or DSD x64 (DSD also available over UPnP streaming) - TOSLINK: 16-24 bit, 32-192kHz (using high quality TOSLINK optical cable) S/PDIF: Linear PCM 16-24 bit, 32-192kHz AES3/EBU: Linear PCM 16-24 bit, 32-192kHz BT100 Bluetooth receiver: A2DP plus aptX Internet radio: 16-24 bit, 11.025-192kHz
- Audio formatsALAC, WAV, FLAC, AIFF, DSD (x64), WMA, MP3, AAC, HE AAC, AAC+, OGG Vorbis
- Standby power consumption<0.5W
- Dimensions
(H x W x D)115 x 430 x 360mm (4.5 x 16.9 x 14.7”) - Weight8.1kg (17.9lbs)
