Descrizione
Features
- Dual mono PCM1704 24 bit DAC fitted to provide very high resolution and separation
- CD display can be turned off for improved sound quality
- Highly optimised audio circuitry with discrete output stage and multiple stages of regulation
- Large toroidal power transformer with separate windings for CD transport mechanism and audio stages
- Employment of a high-stability crystal clock reference and dedicated, power supply regulator for the transport and audio stages to ensure low jitter performance
- High quality double-sided PCBs for optimum layout and screening
- All-aluminium casework and extruded front panel to control resonance and stray electro-magnetic fields
- Full-function remote control
- Three year guarantee
- Available in black or titanium
Specifications
-
- Output Level : 2V RMS
- Frequency Response : 20Hz – 20KHz ± 0.25dB
- Total Harmonic Distortion : <0.008%, 20Hz – 20KHz, 0dBFs
- Signal to Noise Ratio : >100dB, A weighted
- Digital Outputs : SP/DIF, Coaxial and “Toslink” Optical
- Mains Supply : 110/120V or 220/240V, 50/60Hz (factory set)
- Power Consumption : <25 VA
- Dimensions – H x W x D : 90mm x 440mm x 300mm
- Nett Weight (unpacked) : 5kg
- Gross Weight (packed) : 7kg
